C#chart之PieChart

編輯:C#入門知識

C#chart之PieChart








using System.Web.UI.DataVisualization.Charting;
using System.Drawing;

namespace Chart.AJAX
{
    public partial class Export_AJAX : System.Web.UI.Page
    {
        void CreateChart()
        {
            string[] xValues = { 0-20, 20-30, 30-40, 40-50, 50-60, > 60, unknow };
            int[] yValues = {5, 18, 45, 17, 2, 1, 162 };

            //ChartAreas,Series,Legends 基本設定-------------------------------------------------
            Chart Chart1 = new Chart();
            Chart1.ChartAreas.Add(ChartArea1); //圖表區域集合
            Chart1.Legends.Add(Legends1); //圖例集合說明
            Chart1.Series.Add(Series1); //數據序列集合

            //設定 Chart-------------------------------------------------------------------------
            Chart1.Width = 770;
            Chart1.Height = 400;
            Title title = new Title();
            title.Text = titleStr;
            title.Alignment = ContentAlignment.MiddleCenter;
            title.Font = new System.Drawing.Font(Trebuchet MS, 14F, FontStyle.Bold);
            Chart1.Titles.Add(title);

            //設定 ChartArea1--------------------------------------------------------------------
            Chart1.ChartAreas[ChartArea1].Area3DStyle.Enable3D = is3D;
            Chart1.ChartAreas[0].AxisX.Interval = 1;

            //設定 Legends-------------------------------------------------------------------------
            //Chart1.Legends[Legends1].DockedToChartArea = ChartArea1; //顯示在圖表內
            //Chart1.Legends[Legends1].Docking = Docking.Bottom; //自訂顯示位置
            //背景色
            Chart1.Legends[Legends1].BackColor = Color.FromArgb(235, 235, 235);
            //斜線背景
            Chart1.Legends[Legends1].BackHatchStyle = ChartHatchStyle.DarkDownwardDiagonal;
            Chart1.Legends[Legends1].BorderWidth = 1;
            Chart1.Legends[Legends1].BorderColor = Color.FromArgb(200, 200, 200);

            //設定 Series1-----------------------------------------------------------------------
            Chart1.Series[Series1].ChartType = SeriesChartType.Pie;
            //Chart1.Series[Series1].ChartType = SeriesChartType.Doughnut;
            Chart1.Series[Series1].Points.DataBindXY(xValues, yValues);
            Chart1.Series[Series1].LegendText = #VALX:    [ #PERCENT{P1} ]; //X軸 + 百分比
            Chart1.Series[Series1].Label = #VALX
#PERCENT{P1}; //X軸 + 百分比
            //Chart1.Series[Series1].LabelForeColor = Color.FromArgb(0, 90, 255); //字體顏色
            //字體設定
            Chart1.Series[Series1].Font = new System.Drawing.Font(Trebuchet MS, 10, System.Drawing.FontStyle.Bold);
            Chart1.Series[Series1].Points.FindMaxByValue().LabelForeColor = Color.Red;
            //Chart1.Series[Series1].Points.FindMaxByValue().Color = Color.Red;
            //Chart1.Series[Series1].Points.FindMaxByValue()[Exploded] = true;
            Chart1.Series[Series1].BorderColor = Color.FromArgb(255, 101, 101, 101);

            //Chart1.Series[Series1][DoughnutRadius] = 80; // ChartType為Doughnut時,Set Doughnut hole size
            //Chart1.Series[Series1][PieLabelStyle] = Inside; //數值顯示在圓餅內
            Chart1.Series[Series1][PieLabelStyle] = Outside; //數值顯示在圓餅外
            //Chart1.Series[Series1][PieLabelStyle] = Disabled; //不顯示數值
            //設定圓餅效果,除 Default 外其他效果3D不適用
            Chart1.Series[Series1][PieDrawingStyle] = Default;
            //Chart1.Series[Series1][PieDrawingStyle] = SoftEdge;
            //Chart1.Series[Series1][PieDrawingStyle] = Concave;

            //Random rnd = new Random();  //亂數產生區塊顏色
            //foreach (DataPoint point in Chart1.Series[Series1].Points)
            //{
            //    //pie 顏色
            //    point.Color = Color.FromArgb(150, rnd.Next(0, 255), rnd.Next(0, 255), rnd.Next(0, 255));
            //}
            Page.Controls.Add(Chart1);
        }
    }
}
