C#中WinForm控件的拖動和縮放的完成代碼

編輯:C#入門知識

C#中WinForm控件的拖動和縮放的完成代碼。本站提示廣大學習愛好者:(C#中WinForm控件的拖動和縮放的完成代碼)文章只能為提供參考,不一定能成為您想要的結果。以下是C#中WinForm控件的拖動和縮放的完成代碼正文


C# WinForm控件的拖動和縮放是個很有用的功用。完成起來其實很復雜的,次要是設計控件的MouseDown、MouseLeave、MouseMove事情,上面的幾個步驟將逐漸完成C# WinForm控件的拖動和縮放的功用。

1、定義一個枚舉類型,描繪光標形態

private enum EnumMousePointPosition
  {
  MouseSizeNone  = 0, //'無
  MouseSizeRight  = 1, //'拉伸左邊框
  MouseSizeLeft  = 2, //'拉伸右邊框
  MouseSizeBottom  = 3, //'拉伸下邊框
  MouseSizeTop  = 4, //'拉伸上邊框
  MouseSizeTopLeft = 5, //'拉伸左上角
  MouseSizeTopRight = 6, //'拉伸右上角
  MouseSizeBottomLeft = 7, //'拉伸左下角
  MouseSizeBottomRight= 8, //'拉伸右下角
  MouseDrag  = 9  // '鼠標拖動
  }

2、定義幾個變量

 const int Band = 5;
  const int MinWidth=10;
  const int MinHeight=10;
  private EnumMousePointPosition m_MousePointPosition;
  private Point p,p1;

3、定義自己的MyMouseDown事情

private void MyMouseDown(object sender,System.Windows.Forms.MouseEventArgs e)
{
 p.X=e.X;
 p.Y=e.Y;
 p1.X=e.X;
 p1.Y=e.Y;
}

4、定義自己的MyMouseLeave事情

 private void MyMouseLeave(object sender, System.EventArgs e)
{
 m_MousePointPosition = EnumMousePointPosition.MouseSizeNone;
 this.Cursor=Cursors.Arrow;
}

5、設計一個函數,確定光標在控件不同地位的款式

private EnumMousePointPosition MousePointPosition(Size size,System.Windows.Forms.MouseEventArgs e)
{

 if ((e.X >= -1 * Band) | (e.X <= size.Width) | (e.Y >= -1 * Band) | (e.Y <= size.Height))
 {
 if (e.X < Band)
 {
  if (e.Y < Band) {return EnumMousePointPosition.MouseSizeTopLeft;}
  else
  {
  if (e.Y > -1 * Band + size.Height)
  {return EnumMousePointPosition.MouseSizeBottomLeft;}
  else
  {return EnumMousePointPosition.MouseSizeLeft;}
  }
 }
 else
 {
  if (e.X > -1 * Band + size.Width)
  {
  if (e.Y < Band)
  {return EnumMousePointPosition.MouseSizeTopRight;}
  else
  {
   if (e.Y > -1 * Band + size.Height)
   {return EnumMousePointPosition.MouseSizeBottomRight;}
   else
   {return EnumMousePointPosition.MouseSizeRight;}
  }
  }
  else
  {
  if (e.Y < Band)
  {return EnumMousePointPosition.MouseSizeTop;}
  else
  {
   if (e.Y > -1 * Band + size.Height)
   {return EnumMousePointPosition.MouseSizeBottom;}
   else
   {return EnumMousePointPosition.MouseDrag;}
  }
  }
 }
 }
 else
 {return EnumMousePointPosition.MouseSizeNone;}
}

6、定義自己的MyMouseMove事情,在這個事情裡,會運用下面設計的函數

  private void MyMouseMove(object sender,System.Windows.Forms.MouseEventArgs e)
  {
  Control lCtrl =(sender as Control);

  if (e.Button==MouseButtons.Left)
  {
   switch (m_MousePointPosition)
   {
   case EnumMousePointPosition.MouseDrag:
    lCtrl.Left =lCtrl.Left+ e.X - p.X;
    lCtrl.Top =lCtrl.Top+ e.Y - p.Y;
    break;
   case EnumMousePointPosition.MouseSizeBottom:
    lCtrl.Height = lCtrl.Height + e.Y - p1.Y;
    p1.X=e.X;
    p1.Y=e.Y; //'記載光標拖動的以後點
    break;
   case EnumMousePointPosition.MouseSizeBottomRight:
    lCtrl.Width  = lCtrl.Width + e.X - p1.X;
    lCtrl.Height = lCtrl.Height + e.Y - p1.Y;
    p1.X=e.X;
    p1.Y=e.Y; //'記載光標拖動的以後點
    break;
   case EnumMousePointPosition.MouseSizeRight:
    lCtrl.Width  = lCtrl.Width + e.X - p1.X;
//    lCtrl.Height = lCtrl.Height + e.Y - p1.Y;
    p1.X=e.X;
    p1.Y=e.Y; //'記載光標拖動的以後點
    break;
   case EnumMousePointPosition.MouseSizeTop:
    lCtrl.Top  = lCtrl.Top + (e.Y - p.Y);
    lCtrl.Height = lCtrl.Height - (e.Y - p.Y);
    break;
   case EnumMousePointPosition.MouseSizeLeft:
    lCtrl.Left  = lCtrl.Left + e.X - p.X;
    lCtrl.Width  = lCtrl.Width - (e.X - p.X);
    break;
   case EnumMousePointPosition.MouseSizeBottomLeft:
    lCtrl.Left  = lCtrl.Left + e.X - p.X;
    lCtrl.Width  = lCtrl.Width - (e.X - p.X);
    lCtrl.Height = lCtrl.Height+ e.Y - p1.Y;
    p1.X=e.X;
    p1.Y=e.Y; //'記載光標拖動的以後點
    break;
   case EnumMousePointPosition.MouseSizeTopRight:
    lCtrl.Top  = lCtrl.Top + (e.Y - p.Y);
    lCtrl.Width  = lCtrl.Width + (e.X - p1.X);
    lCtrl.Height = lCtrl.Height - (e.Y - p.Y);
    p1.X=e.X;
    p1.Y=e.Y; //'記載光標拖動的以後點
    break;
   case EnumMousePointPosition.MouseSizeTopLeft:
    lCtrl.Left  = lCtrl.Left + e.X - p.X;
    lCtrl.Top  = lCtrl.Top + (e.Y - p.Y);
    lCtrl.Width  = lCtrl.Width - (e.X - p.X);
    lCtrl.Height = lCtrl.Height - (e.Y - p.Y);
    break;
   default:
    break;
   }
   if (lCtrl.Width<MinWidth) lCtrl.Width=MinWidth;
   if (lCtrl.Height<MinHeight) lCtrl.Height=MinHeight;

  }
  else
  {
   m_MousePointPosition = MousePointPosition(lCtrl.Size, e);  //'判別光標的地位形態
   switch (m_MousePointPosition)  //'改動光標
   {
   case EnumMousePointPosition.MouseSizeNone:
    this.Cursor = Cursors.Arrow;    //'箭頭
    break;
   case EnumMousePointPosition.MouseDrag:
    this.Cursor = Cursors.SizeAll;   //'四方向
    break;
   case EnumMousePointPosition.MouseSizeBottom:
    this.Cursor = Cursors.SizeNS;    //'南北
    break;
   case EnumMousePointPosition.MouseSizeTop:
    this.Cursor = Cursors.SizeNS;    //'南北
    break;
   case EnumMousePointPosition.MouseSizeLeft:
    this.Cursor = Cursors.SizeWE;    //'東西
    break;
   case EnumMousePointPosition.MouseSizeRight:
    this.Cursor = Cursors.SizeWE;    //'東西
    break;
   case EnumMousePointPosition.MouseSizeBottomLeft:
    this.Cursor = Cursors.SizeNESW;   //'西南到南西
    break;
   case EnumMousePointPosition.MouseSizeBottomRight:
    this.Cursor = Cursors.SizeNWSE;   //'西北到東南
    break;
   case EnumMousePointPosition.MouseSizeTopLeft:
    this.Cursor = Cursors.SizeNWSE;   //'西北到東南
    break;
   case EnumMousePointPosition.MouseSizeTopRight:
    this.Cursor = Cursors.SizeNESW;   //'西南到南西
    break;
   default:
    break;
   }
  }

  }

7、制造一個初始化進程,將界面panel1上的一切控件都綁定MyMouseDown、MyMouseLeave、MyMouseMove事情,記得在Form初始化或許Form_Load時先執行它。

 private void initProperty()
{
 for(int i = 0; i < this.panel1.Controls.Count; i++)
 {
 this.panel1.Controls[i].MouseDown+= new System.Windows.Forms.MouseEventHandler(MyMouseDown);
 this.panel1.Controls[i].MouseLeave+= new System.EventHandler(MyMouseLeave);
 this.panel1.Controls[i].MouseMove += new System.Windows.Forms.MouseEventHandler(MyMouseMove);
 }

}

8、ok,在運轉之前你在panel1上放幾個控件,執行順序,應該可以隨意挪動、改動其大小了

C# WinForm控件的拖動和縮放的完成就此完成。

以上就是本文的全部內容,希望對大家的學習有所協助,也希望大家多多支持。
