再學GDI+[32]: TGPPen - 拐角長度的限制 - SetMiterLimit

拐角長度的限制的默認值是 10.0, 一般足夠用了.

本例效果圖:

代碼文件:unit Unit1;
interface
uses
　Windows, Messages, SysUtils, Variants, Classes, Graphics, Controls, Forms,
　Dialogs, StdCtrls, ComCtrls;
type
　TForm1 = class(TForm)
　　TrackBar1: TTrackBar;
　　procedure FormPaint(Sender: TObject);
　　procedure ListBox1Click(Sender: TObject);
　　procedure TrackBar1Change(Sender: TObject);
　　procedure FormCreate(Sender: TObject);
　end;
var
　Form1: TForm1;
implementation
{$R *.dfm}
uses GDIPOBJ, GDIPAPI;
procedure TForm1.FormCreate(Sender: TObject);
begin
　TrackBar1.ShowSelRange := False;
　TrackBar1.Height := 20;
　TrackBar1.Min := 0;
　TrackBar1.Max := 100;
　TrackBar1.Position := TrackBar1.Max;
end;
procedure TForm1.FormPaint(Sender: TObject);
const
　PtArr: array[0..2] of TGPPoint = ((X:90;Y:80), (X:240;Y:30), (X:240;Y:80));
var
　g: TGPGraphics;
　p: TGPPen;
begin
　g := TGPGraphics.Create(Canvas.Handle);
　p := TGPPen.Create(aclSeaGreen, 28);
　p.SetMiterLimit(TrackBar1.Position / 10);
　g.DrawPolygon(p, PGPPoint(@PtArr), Length(PtArr));
　p.Free;
　g.Free;
end;
procedure TForm1.ListBox1Click(Sender: TObject);
begin
　Repaint;
end;
procedure TForm1.TrackBar1Change(Sender: TObject);
begin
　Repaint;
end;
end.
