How to use Python to create a GUI student management system with full marks given by teachers

編輯:Python

order said

Hello, everyone. Hello, duck ! I'm a panda

Has anything interesting happened recently ? Come and tell me ( •̀ ω •́ )*

My cousin is about to graduate from college ,
Studied for a semester Python I can't even write a student management system ,
It really humiliates me , Teach him and refuse to learn ,
And let me write directly to him ,
I really want to slap my hands ,
Finally I wrote it to him ,
Who makes him my cousin ,
I still have to help him at the critical moment !

After writing, I put it there , So let's share it with you today !

Don't talk much , Let's go straight ahead !

Code parsing (https://jq.qq.com/?_wv=1027&k=3uTc6UFb)

One 、 The login page (https://jq.qq.com/?_wv=1027&k=3uTc6UFb)

1、 Define login classes and initialization objects
First, import the modules we need

from main import MainPage

The login page

Bind the palette to the instance object

self.root = master

self.page Drawing paper Show a rectangular area on the screen , It's mostly used as a container .

self.page = tk.Frame(self.root)
self.page.pack()
self.root.geometry("300x180")

tkinter Variable variables provided , Define user name and password .

self.username = tk.StringVar()
self.password = tk.StringVar()

Create a label

Grid layout

tk.Label(self.page).grid(row=0, column=0)
# textvariable This parameter is set to tkinter Inside the string variable and Space bound
tk.Label(self.page, text=" Account ").grid(row=1, column=0, stick=tk.E, pady=10)
tk.Entry(self.page, textvariable=self.username).grid(row=1, column=1, stick=tk.W, pady=10)
tk.Label(self.page, text=" password ").grid(row=2, column=0, stick=tk.E, pady=10)
tk.Entry(self.page, textvariable=self.password).grid(row=2, column=1, stick=tk.W, pady=10)

command Accept a function Execute login logic
2、 Login function
Verify login

Get the account code

name = self.username.get()
pwd = self.password.get()

Don't query the database

print(name, pwd)
if name == 'admin' and pwd == '123456':
tkinter.messagebox.showinfo(title=' Congratulations ',
message=' Login successful !')

Destroy the content drawn on the current page

self.page.destroy()

Destroy the contents drawn on the whole page

self.root.destroy()

Page switching

 MainPage(self.root)
else:
tkinter.messagebox.showinfo(title=' error ', message=' Wrong account or password ')

3、 Window call
Call this file method , Run two inputs in this file , The data before the method is called and executed outside .

Create an object , Window object , display .

if __name__ == '__main__':
root = tk.Tk()
LoginPage(root)
root.mainloop()

Two 、 The main page displays (https://jq.qq.com/?_wv=1027&k=3uTc6UFb)

1、 Define page classes , Convenient to call .

Login screen

def __init__(self, master):
self.root = master
self.page = tk.Frame(self.root)
self.page.pack()
self.root.geometry("%dx%d" % (600, 400))
self.create_page()

Create a top-level menu , Show menu .

def create_page(self):
menubar = tk.Menu(self.root)
menubar.add_command(label=" entry ")
menubar.add_command(label=" Inquire about ")
menubar.add_command(label=" Delete ")
menubar.add_command(label=" modify ")
menubar.add_command(label=" About ")

3、 ... and 、 Page shows (https://jq.qq.com/?_wv=1027&k=3uTc6UFb)

1、 Bind each page
Too much code written together , More data , It's easy to write wrong , confusion , You can write a file to hold data view.py

stay view.py The file defines the classes of each module

entry

class InputFrame(tk.Frame): # Inherit Frame class
def __init__(self, master):
# Re parent
super().__init__(master)
pass

Inquire about

class QueryFrame(tk.Frame): # Inherit Frame class
def __init__(self, master=None):
super().__init__(master)
pass

Delete

class DeleteFrame(tk.Frame): # Inherit Frame class
def __init__(self, master=None):
super().__init__(master)

modify

class ChangeFrame(tk.Frame): # Inherit Frame class
def __init__(self, master=None):
super().__init__(master)

About

class AboutFrame(tk.Frame): # Inherit Frame class
def __init__(self, master=None):
tk.Frame.__init__(self, master)
self.root = master

And then in main.py Bind the data in the file

self.input_page = InputFrame(self.root)
self.change_page = ChangeFrame(self.root)
self.query_page = QueryFrame(self.root)
self.delete_page = DeleteFrame(self.root)
self.about_page = AboutFrame(self.root)

2、 entry
stay view.py In file InputFrame Class , Name and grades .

x = IntVar(): Integer variables , The default is 0
x = DoubleVar(): Floating point variables , The default is 0.0
x = StringVar(): String variable , The default is ""
x = BooleanVar(): Boolean variables ,True yes 1,False yes 0

self.root = master # Define internal variables root
self.name = tk.StringVar()
self.math = tk.StringVar()
self.chinese = tk.StringVar()
self.english = tk.StringVar()
# entry
self.status = tk.StringVar()
# call create_page() function
self.create_page()

To write create_page() function

def create_page(self):
# pass
# stick Control object orientation tk.W Western bit
# pady padding y Width up and down
# row That's ok Table layout
tk.Label(self).grid(row=0, stick=tk.W, pady=10)
tk.Label(self, text=' surname name : ').grid(row=1, stick=tk.W, pady=10)
# text variable Bind the data content in the control
tk.Entry(self, textvariable=self.name).grid(row=1, column=1, stick=tk.E)
tk.Label(self, text=' Count learn : ').grid(row=2, stick=tk.W, pady=10)
tk.Entry(self, textvariable=self.math).grid(row=2, column=1, stick=tk.E)
tk.Label(self, text=' language writing : ').grid(row=3, stick=tk.W, pady=10)
tk.Entry(self, textvariable=self.chinese).grid(row=3, column=1, stick=tk.E)
tk.Label(self, text=' Britain language : ').grid(row=4, stick=tk.W, pady=10)
tk.Entry(self, textvariable=self.english).grid(row=4, column=1, stick=tk.E)
tk.Button(self, text=' entry ', command=self.recode_student).grid(row=5, column=1, stick=tk.E, pady=10)
tk.Label(self, textvariable=self.status).grid(row=6, column=1, stick=tk.E, pady=10)

stay main.py Bind these data in

menubar.add_command(label=" entry ", command=self.show_input)
def show_input(self):
self.input_page.pack()
# pack_forget() Hide layout
# self.change_page.pack_forget()
# self.query_page.pack_forget()
# self.delete_page.pack_forget()
# self.about_page.pack_forget()

stay view.py Data entry in the document

def recode_student(self):
stu = {'name': self.name.get(), 'chinese': self.chinese.get(),
'math': self.math.get(), 'english': self.english.get()}
# You need to refresh the page after clicking and entering
self.name.set('')
self.chinese.set('')
self.math.set('')
self.english.set('')
db.insert(stu)
self.status.set(' Data submitted successfully ')
print(stu)

Insert data and save data , Can write a file to save , Too much code to write together , The probability of error is also one db.py file .

class StudentsDB:
def __init__(self):
self.students = []
def insert(self, student):
self.students.append(student)
db = StudentsDB()
if __name__ == '__main__':
print(db.students)

Four 、 Query data (https://jq.qq.com/?_wv=1027&k=3uTc6UFb)

stay QueryFrame() Class to add data

  • ttk.Treeview Tree view , use Baidu Search
  • shows:
    headings
    tree
    data_list
  • columns

The value is a list . Each element in the list represents the name of a column identifier . The length of the list is the length of the column .

Inherit Frame class

class QueryFrame(tk.Frame):
def __init__(self, master=None):
super().__init__(master)

Define internal variables root

self.root = master #
columns = ('name', 'chinese', 'math', 'english')
self.tree_view = ttk.Treeview(self, show='headings', columns=columns)

Each data size is one grid

self.tree_view.column('name', width=80, anchor='center')
self.tree_view.column('chinese', width=80, anchor='center')
self.tree_view.column('math', width=80, anchor='center')
self.tree_view.column('english', width=80, anchor='center')

The above label and headings

self.tree_view.heading('name', text=' full name ')
self.tree_view.heading('chinese', text=' Chinese language and literature ')
self.tree_view.heading('math', text=' mathematics ')
self.tree_view.heading('english', text=' English ')
self.tree_view.pack(fill=tk.BOTH, expand=True)
tk.Button(self, text=' The refresh data ', command=self.show_data_frame).pack(anchor=tk.E, pady=5)
self.show_data_frame()

The refresh data , Display the data .

def show_data_frame(self):
# Delete old stage
for _ in map(self.tree_view.delete, self.tree_view.get_children('')):
pass
# First show all the data stay db Add the display data code to the file
students = db.all()
index = 0
for stu in students:
# print(stu)
self.tree_view.insert('', index + 1, values=(
stu['name'], stu['chinese'], stu['math'], stu['english'],
))

Display the data

stay db.py To add

def all(self):
return self.students

view.py

Refresh insert data

  • The first parameter :parent : For those with tree Columns Treeview,parent Is the parent node , For the list column only Treeview,parent It is generally empty .
  • The second parameter :index : Insertion position . It can be END or ’end’
    , It can also be digital , If you want to insert new item( Record ) Become the first of a node ,index Set it to 0, And so on .
  • values: Displayed values and inserted data , This column of data .
self.tree_view.insert('', index + 1, values=(
stu['name'], stu['chinese'], stu['math'], stu['english'],
))

Update page after inserting data refresh

  • map(func, lst), The function variable passed in func Effect to lst In each element of the variable , And make a new list of the results (Python2)/ iterator (Python3) return .
  • get_children(item=None)

Return to one item All son item, This one item It's a list , If item It's not specified , Returns the of the root directory item

for _ in map(self.tree_view.delete, self.tree_view.get_children('')):
pass

stay main.py File binding data

 menubar.add_command(label=" Inquire about ", command=self.show_all)
def show_all(self):
# Hide layout
self.input_page.pack_forget()
# self.change_page.pack_forget()
self.query_page.pack()
# self.delete_page.pack_forget()
# self.about_page.pack_forget()

5、 ... and 、 Delete data

stay DeleteFrame() Class to add data

class DeleteFrame(tk.Frame): # Inherit Frame class
def __init__(self, master=None):
super().__init__(master)
self.root = master # Define internal variables root
tk.Label(self, text=' Delete data ').pack()
self.delete_frame = tk.Frame(self)
self.delete_frame.pack()
self.status = tk.StringVar()
self.username = tk.StringVar()
tk.Label(self.delete_frame, text=' Delete information by name ').pack(anchor=tk.W, padx=20)
tk.Entry(self.delete_frame, textvariable=self.username).pack(side=tk.LEFT, padx=20, pady=5)
tk.Button(self.delete_frame, text=' Delete ', command=self._delete).pack()
tk.Label(self, textvariable=self.status).pack()

1、 Click delete , Delete data

def _delete(self):
username = self.username.get()
flag, message = db.delete_by_name(username)
self.status.set(message)

stay db.py Add delete logic to the file

def delete_by_name(self, name):
for student in self.students:
if name == student['name']:
self.students.remove(student)
return True, f'{name} Delete successful '
return False, f'{name} non-existent '

stay main.py Binding data in

 menubar.add_command(label=" Delete ", command=self.show_delete)
def show_delete(self):
self.input_page.pack_forget()
self.query_page.pack_forget()
self.delete_page.pack()

6、 ... and 、 Modifying data

stay ChangeFrame() Class to add data

self.root = master # Define internal variables root
tk.Label(self, text=' Modify the interface ').pack()
self.change_frame = tk.Frame(self)
self.change_frame.pack()
self.status = tk.StringVar()
self.name = tk.StringVar()
self.math = tk.StringVar()
self.chinese = tk.StringVar()
self.english = tk.StringVar()
tk.Label(self.change_frame).grid(row=0, stick=tk.W, pady=1)
tk.Label(self.change_frame, text=' surname name : ').grid(row=1, stick=tk.W, pady=10)
tk.Entry(self.change_frame, textvariable=self.name).grid(row=1, column=1, stick=tk.E)
tk.Label(self.change_frame, text=' Count learn : ').grid(row=2, stick=tk.W, pady=10)
tk.Entry(self.change_frame, textvariable=self.math).grid(row=2, column=1, stick=tk.E)
tk.Label(self.change_frame, text=' language writing : ').grid(row=3, stick=tk.W, pady=10)
tk.Entry(self.change_frame, textvariable=self.chinese).grid(row=3, column=1, stick=tk.E)
tk.Label(self.change_frame, text=' Britain language : ').grid(row=4, stick=tk.W, pady=10)
tk.Entry(self.change_frame, textvariable=self.english).grid(row=4, column=1, stick=tk.E)
tk.Button(self.change_frame, text=' Inquire about ', command=self._search).grid(row=6, column=0, stick=tk.W, pady=10)
tk.Button(self.change_frame, text=' modify ', command=self._change).grid(row=6, column=1, stick=tk.E, pady=10)
tk.Label(self.change_frame, textvariable=self.status).grid(row=7, column=1, stick=tk.E, pady=10)

1、 Query data

db.py Query data logic in file

def search_by_name(self, name):
for student in self.students:
if name == student['name']:
return True, student
return False, f'{name} non-existent '

view.py Click to query the file , Display the data

def _search(self):
flag, info = db.search_by_name(self.name.get())
if flag:
self.name.set(info['name'])
self.chinese.set(info['chinese'])
self.math.set(info['math'])
self.english.set(info['english'])
self.status.set(' Data query successful ')
else:
# Return the error information directly
self.status.set(info)

2、 Modify data and update
db.py File update data logic

def update(self, stu):
name = stu['name']
for student in self.students:
if name == student['name']:
student.update(stu)
return True, f'{stu["name"]} User data modified successfully '
else:
return False, f'{name} non-existent '

view.py File modification data

def _change(self):
stu = {'name': self.name.get(), 'chinese': self.chinese.get(),
'math': self.math.get(), 'english': self.english.get(), }
self.name.set('')
self.chinese.set('')
self.math.set('')
self.english.set('')
db.update(stu)
self.status.set(' Data modified successfully ')

main.py File binding

 menubar.add_command(label=" modify ", command=self.show_change)
def show_change(self):
self.input_page.pack_forget()
self.query_page.pack_forget()
self.delete_page.pack_forget()
self.change_page.pack()

7、 ... and 、 About the part

view.py In the AboutFrame() Add data

class AboutFrame(tk.Frame): # Inherit Frame class
def __init__(self, master=None):
tk.Frame.__init__(self, master)
self.root = master # Define internal variables root
tk.Label(self, text=' About the work : This work is written by Panda aiqiafan Make ').pack(anchor=tk.W)
tk.Label(self, text=' About author : Panda aiqiafan ').pack(anchor=tk.W)
tk.Label(self, text=' copyright : Panda aiqiafan ').pack(anchor=tk.W)

main.py Data binding

 menubar.add_command(label=" About ", command=self.show_about)
def show_about(self):
self.input_page.pack_forget()
self.query_page.pack_forget()
self.delete_page.pack_forget()
self.change_page.pack_forget()
self.about_page.pack()

8、 ... and 、 Save the data , Save information

db.py Save the data

Create an empty json file

import os
file = "students.json"
# Judge whether the file exists , Create if it does not exist
if not os.path.exists(file):
open(file, 'w')
# Report errors
# os.mknod(file)
  • Windows Upper Python I won't support it mknod function , Because in Windows Not on node The concept .

1、 Save the data

def save_data(self):
with open('students.json', mode='w', encoding='utf-8') as f:
text = json.dumps(self.students, indent=2, ensure_ascii=False)
f.write(text)

2 、 Reading data

def _load_students_data(self):
with open('students.json', mode='r', encoding='utf-8') as f:
text = f.read()
if text:
self.students = json.loads(text)

stay view.py File to call the save function , Save the completed data .

entry

def recode_student(self):
db.save_data()

Delete

def _delete(self):
db.save_data()

modify

def _change(self):
db.save_data()

The article is incomprehensible , I specially recorded the corresponding video to explain , This article is just a general demonstration of , Click the contact information below for the complete code and video tutorial ↓↓↓↓ Scan the code to get ↓↓↓↓

Well, today's sharing is here , See you next time, guys !

If you think it helps , Let's take a look + Fabulous + Collect it , Love you !

I'm a panda , See you in the next article (*◡‿◡)


  1. 上一篇文章:
  2. 下一篇文章:
Copyright © 程式師世界 All Rights Reserved
