Hello, brothers , Long time no see ！ I'm really busy these days , So once again broke up again ~
My cousin is about to graduate from college , Studied for a semester Python I can't even write a student management system , It really humiliates me , Teach him and refuse to learn , And let me write directly to him , I really want to slap my hands , Finally I wrote it to him , Who makes him my cousin , I still have to help him at the critical moment ！
After writing, I put it there , So let's share it with you today ！
Don't talk much , Let's go straight ahead ！
First, import the modules we need
from main import MainPage
The login page
Bind the palette to the instance object
self.root = master
self.page Drawing paper Show a rectangular area on the screen , It's mostly used as a container .
self.page = tk.Frame(self.root)
self.page.pack()
self.root.geometry("300x180")
tkinter Variable variables provided , Define user name and password .
self.username = tk.StringVar()
self.password = tk.StringVar()
Create a label
Grid layout
tk.Label(self.page).grid(row=0, column=0)
# textvariable This parameter is set to tkinter Inside the string variable and Space bound
tk.Label(self.page, text=" Account ").grid(row=1, column=0, stick=tk.E, pady=10)
tk.Entry(self.page, textvariable=self.username).grid(row=1, column=1, stick=tk.W, pady=10)
tk.Label(self.page, text=" password ").grid(row=2, column=0, stick=tk.E, pady=10)
tk.Entry(self.page, textvariable=self.password).grid(row=2, column=1, stick=tk.W, pady=10)
command Accept a function Execute login logic
tk.Button(self.page, text=" Sign in ", command=self.login_check).grid(row=3, column=0, stick=tk.W, pady=10)
tk.Button(self.page, text=" sign out ", command=root.quit).grid(row=3, column=1, stick=tk.E, pady=10)
Verify login
Get the account code
name = self.username.get()
pwd = self.password.get()
Don't query the database
print(name, pwd)
if name == 'admin' and pwd == '123456':
tkinter.messagebox.showinfo(title=' Congratulations ',
message=' Login successful ！')
Destroy the content drawn on the current page
self.page.destroy()
Destroy the contents drawn on the whole page
self.root.destroy()
Page switching
MainPage(self.root)
else:
tkinter.messagebox.showinfo(title=' error ', message=' Wrong account or password ')
Call this file method , Run two inputs in this file , The data before the method is called and executed outside .
Create an object , Window object , display .
if __name__ == '__main__':
root = tk.Tk()
LoginPage(root)
root.mainloop()
Login screen
def __init__(self, master):
self.root = master
self.page = tk.Frame(self.root)
self.page.pack()
self.root.geometry("%dx%d" % (600, 400))
self.create_page()
Create a top-level menu , Show menu .
def create_page(self):
menubar = tk.Menu(self.root)
menubar.add_command(label=" entry ")
menubar.add_command(label=" Inquire about ")
menubar.add_command(label=" Delete ")
menubar.add_command(label=" modify ")
menubar.add_command(label=" About ")
Too much code written together , More data , It's easy to write wrong , confusion , You can write a file to hold data view.py
stay view.py The file defines the classes of each module
entry
class InputFrame(tk.Frame): # Inherit Frame class
def __init__(self, master):
# Re parent
super().__init__(master)
pass
Inquire about
class QueryFrame(tk.Frame): # Inherit Frame class
def __init__(self, master=None):
super().__init__(master)
pass
Delete
class DeleteFrame(tk.Frame): # Inherit Frame class
def __init__(self, master=None):
super().__init__(master)
modify
class ChangeFrame(tk.Frame): # Inherit Frame class
def __init__(self, master=None):
super().__init__(master)
About
class AboutFrame(tk.Frame): # Inherit Frame class
def __init__(self, master=None):
tk.Frame.__init__(self, master)
self.root = master
And then in main.py Bind the data in the file
self.input_page = InputFrame(self.root)
self.change_page = ChangeFrame(self.root)
self.query_page = QueryFrame(self.root)
self.delete_page = DeleteFrame(self.root)
self.about_page = AboutFrame(self.root)
stay view.py In file InputFrame Class , Name and grades .
self.root = master # Define internal variables root
self.name = tk.StringVar()
self.math = tk.StringVar()
self.chinese = tk.StringVar()
self.english = tk.StringVar()
# entry
self.status = tk.StringVar()
# call create_page（） function
self.create_page()
To write create_page() function
def create_page(self):
# pass
# stick Control object orientation tk.W Western bit
# pady padding y Width up and down
# row That's ok Table layout
tk.Label(self).grid(row=0, stick=tk.W, pady=10)
tk.Label(self, text=' surname name : ').grid(row=1, stick=tk.W, pady=10)
# text variable Bind the data content in the control
tk.Entry(self, textvariable=self.name).grid(row=1, column=1, stick=tk.E)
tk.Label(self, text=' Count learn : ').grid(row=2, stick=tk.W, pady=10)
tk.Entry(self, textvariable=self.math).grid(row=2, column=1, stick=tk.E)
tk.Label(self, text=' language writing : ').grid(row=3, stick=tk.W, pady=10)
tk.Entry(self, textvariable=self.chinese).grid(row=3, column=1, stick=tk.E)
tk.Label(self, text=' Britain language : ').grid(row=4, stick=tk.W, pady=10)
tk.Entry(self, textvariable=self.english).grid(row=4, column=1, stick=tk.E)
tk.Button(self, text=' entry ', command=self.recode_student).grid(row=5, column=1, stick=tk.E, pady=10)
tk.Label(self, textvariable=self.status).grid(row=6, column=1, stick=tk.E, pady=10)
stay main.py Bind these data in
menubar.add_command(label=" entry ", command=self.show_input)
def show_input(self):
self.input_page.pack()
# pack_forget() Hide layout
# self.change_page.pack_forget()
# self.query_page.pack_forget()
# self.delete_page.pack_forget()
# self.about_page.pack_forget()
stay view.py Data entry in the document
def recode_student(self):
stu = {
'name': self.name.get(), 'chinese': self.chinese.get(),
'math': self.math.get(), 'english': self.english.get()}
# You need to refresh the page after clicking and entering
self.name.set('')
self.chinese.set('')
self.math.set('')
self.english.set('')
db.insert(stu)
self.status.set(' Data submitted successfully ')
print(stu)
Insert data and save data , Can write a file to save , Too much code to write together , The probability of error is also one db.py file .
class StudentsDB:
def __init__(self):
self.students = []
def insert(self, student):
self.students.append(student)
db = StudentsDB()
if __name__ == '__main__':
print(db.students)
stay QueryFrame() Class to add data
ttk.Treeview Tree view , use Baidu Search
shows：
headings
tree
data_list
columns
The value is a list . Each element in the list represents the name of a column identifier . The length of the list is the length of the column .
Inherit Frame class
class QueryFrame(tk.Frame):
def __init__(self, master=None):
super().__init__(master)
Define internal variables root
self.root = master #
columns = ('name', 'chinese', 'math', 'english')
self.tree_view = ttk.Treeview(self, show='headings', columns=columns)
Each data size is one grid
self.tree_view.column('name', width=80, anchor='center')
self.tree_view.column('chinese', width=80, anchor='center')
self.tree_view.column('math', width=80, anchor='center')
self.tree_view.column('english', width=80, anchor='center')
The above label and headings
self.tree_view.heading('name', text=' full name ')
self.tree_view.heading('chinese', text=' Chinese language and literature ')
self.tree_view.heading('math', text=' mathematics ')
self.tree_view.heading('english', text=' English ')
self.tree_view.pack(fill=tk.BOTH, expand=True)
tk.Button(self, text=' The refresh data ', command=self.show_data_frame).pack(anchor=tk.E, pady=5)
self.show_data_frame()
The refresh data , Display the data .
def show_data_frame(self):
# Delete old stage
for _ in map(self.tree_view.delete, self.tree_view.get_children('')):
pass
# First show all the data stay db Add the display data code to the file
students = db.all()
index = 0
for stu in students:
# print(stu)
self.tree_view.insert('', index + 1, values=(
stu['name'], stu['chinese'], stu['math'], stu['english'],
))
Display the data
stay db.py To add
def all(self):
return self.students
view.py
Refresh insert data
self.tree_view.insert('', index + 1, values=(
stu['name'], stu['chinese'], stu['math'], stu['english'],
))
Update page after inserting data refresh
Return to one item All son item, This one item It's a list , If item It's not specified , Returns the of the root directory item
for _ in map(self.tree_view.delete, self.tree_view.get_children('')):
pass
stay main.py File binding data
menubar.add_command(label=" Inquire about ", command=self.show_all)
def show_all(self):
# Hide layout
self.input_page.pack_forget()
# self.change_page.pack_forget()
self.query_page.pack()
# self.delete_page.pack_forget()
# self.about_page.pack_forget()
stay DeleteFrame() Class to add data
class DeleteFrame(tk.Frame): # Inherit Frame class
def __init__(self, master=None):
super().__init__(master)
self.root = master # Define internal variables root
tk.Label(self, text=' Delete data ').pack()
self.delete_frame = tk.Frame(self)
self.delete_frame.pack()
self.status = tk.StringVar()
self.username = tk.StringVar()
tk.Label(self.delete_frame, text=' Delete information by name ').pack(anchor=tk.W, padx=20)
tk.Entry(self.delete_frame, textvariable=self.username).pack(side=tk.LEFT, padx=20, pady=5)
tk.Button(self.delete_frame, text=' Delete ', command=self._delete).pack()
tk.Label(self, textvariable=self.status).pack()
def _delete(self):
username = self.username.get()
flag, message = db.delete_by_name(username)
self.status.set(message)
stay db.py Add delete logic to the file
def delete_by_name(self, name):
for student in self.students:
if name == student['name']:
self.students.remove(student)
return True, f'{
name} Delete successful '
return False, f'{
name} non-existent '
stay main.py Binding data in
menubar.add_command(label=" Delete ", command=self.show_delete)
def show_delete(self):
self.input_page.pack_forget()
self.query_page.pack_forget()
self.delete_page.pack()
stay ChangeFrame() Class to add data
self.root = master # Define internal variables root
tk.Label(self, text=' Modify the interface ').pack()
self.change_frame = tk.Frame(self)
self.change_frame.pack()
self.status = tk.StringVar()
self.name = tk.StringVar()
self.math = tk.StringVar()
self.chinese = tk.StringVar()
self.english = tk.StringVar()
tk.Label(self.change_frame).grid(row=0, stick=tk.W, pady=1)
tk.Label(self.change_frame, text=' surname name : ').grid(row=1, stick=tk.W, pady=10)
tk.Entry(self.change_frame, textvariable=self.name).grid(row=1, column=1, stick=tk.E)
tk.Label(self.change_frame, text=' Count learn : ').grid(row=2, stick=tk.W, pady=10)
tk.Entry(self.change_frame, textvariable=self.math).grid(row=2, column=1, stick=tk.E)
tk.Label(self.change_frame, text=' language writing : ').grid(row=3, stick=tk.W, pady=10)
tk.Entry(self.change_frame, textvariable=self.chinese).grid(row=3, column=1, stick=tk.E)
tk.Label(self.change_frame, text=' Britain language : ').grid(row=4, stick=tk.W, pady=10)
tk.Entry(self.change_frame, textvariable=self.english).grid(row=4, column=1, stick=tk.E)
tk.Button(self.change_frame, text=' Inquire about ', command=self._search).grid(row=6, column=0, stick=tk.W, pady=10)
tk.Button(self.change_frame, text=' modify ', command=self._change).grid(row=6, column=1, stick=tk.E, pady=10)
tk.Label(self.change_frame, textvariable=self.status).grid(row=7, column=1, stick=tk.E, pady=10)
db.py Query data logic in file
def search_by_name(self, name):
for student in self.students:
if name == student['name']:
return True, student
return False, f'{
name} non-existent '
view.py Click to query the file , Display the data
def _search(self):
flag, info = db.search_by_name(self.name.get())
if flag:
self.name.set(info['name'])
self.chinese.set(info['chinese'])
self.math.set(info['math'])
self.english.set(info['english'])
self.status.set(' Data query successful ')
else:
# Return the error information directly
self.status.set(info)
db.py File update data logic
def update(self, stu):
name = stu['name']
for student in self.students:
if name == student['name']:
student.update(stu)
return True, f'{
stu["name"]} User data modified successfully '
else:
return False, f'{
name} non-existent '
view.py File modification data
def _change(self):
stu = {
'name': self.name.get(), 'chinese': self.chinese.get(),
'math': self.math.get(), 'english': self.english.get(), }
self.name.set('')
self.chinese.set('')
self.math.set('')
self.english.set('')
db.update(stu)
self.status.set(' Data modified successfully ')
main.py File binding
menubar.add_command(label=" modify ", command=self.show_change)
def show_change(self):
self.input_page.pack_forget()
self.query_page.pack_forget()
self.delete_page.pack_forget()
self.change_page.pack()
view.py In the AboutFrame() Add data
class AboutFrame(tk.Frame): # Inherit Frame class
def __init__(self, master=None):
tk.Frame.__init__(self, master)
self.root = master # Define internal variables root
tk.Label(self, text=' About the work ： This work is written by Hey, learn programming Make ').pack(anchor=tk.W)
tk.Label(self, text=' About author ： Hey, learn programming ').pack(anchor=tk.W)
tk.Label(self, text=' copyright ： Hey, learn programming ').pack(anchor=tk.W)
main.py Data binding
menubar.add_command(label=" About ", command=self.show_about)
def show_about(self):
self.input_page.pack_forget()
self.query_page.pack_forget()
self.delete_page.pack_forget()
self.change_page.pack_forget()
self.about_page.pack()
db.py Save the data
Create an empty json file
import os
file = "students.json"
# Judge whether the file exists , Create if it does not exist
if not os.path.exists(file):
open(file, 'w')
# Report errors
# os.mknod(file)
def save_data(self):
with open('students.json', mode='w', encoding='utf-8') as f:
text = json.dumps(self.students, indent=2, ensure_ascii=False)
f.write(text)
def _load_students_data(self):
with open('students.json', mode='r', encoding='utf-8') as f:
text = f.read()
if text:
self.students = json.loads(text)
stay view.py File to call the save function , Save the completed data .
entry
def recode_student(self):
db.save_data()
Delete
def _delete(self):
db.save_data()
modify
def _change(self):
db.save_data()
The article is incomprehensible , I specially recorded the corresponding video to explain , This article is just a general demonstration of , Click the contact information below for the complete code and video tutorial ↓↓↓↓ Scan the code to get ↓↓↓↓
Well, today's sharing is here , See you next time, guys ！
If you think it helps , Let's take a look + Fabulous + Collect it , Love you ！
