上一篇介紹了基於Networks of Borkers的2節點HA方案,這一篇繼續來折騰Networks of Brokers,當應用規模日漸增長時,2節點的broker可能仍然抗不住訪問壓力,這時候就需要多加一些broker,弄一個更大規模的Broker集群,但是怎麼合理設置broker之間的網絡橋接,卻是有講究的,先來看一種不太好的設計:
這個架構看上去沒瑕疵,沒毛病,3個broker之間兩兩互通,整體可用性極高,但是從消息的路由角度來看,卻不是一個好的設計,當producer向broker1發送一條消息時,Consumer得到消息的路徑可能有如下2條:
a) producer -> broker1 -> broker2
b) producer -> broker1 -> broker3 -> broker2
當broker更多時,情況會更復雜,比如下面這張圖:
消息的路由途徑將會更多:
a) producer -> broker1 -> broker4
b) producer -> broker1 -> broker2 -> broker4
c) producer -> broker1 -> broker2 -> broker3 -> broker4
d) producer -> broker1 -> broker3 -> broker4
不難想像,每多經過一個節點,消息處理的延時將會增加一些,如果Broker越多,情況越復雜,最終系統對外表現為消息處理有時很快,有時很慢,整體性能很不穩定,所以實際生產中,不要采用所有Broker之間兩兩互連的方案。
合理的方案如下:
這張圖的靈感,應該來自組建局域網中的星形網絡,在中心放置一個Borker充當Hub,與其它所有Broker互連,這樣不管Consumer連接到外圍的哪個Broker,消息的路由途徑都比較穩定(最多經過3個Broker),這種架構性能雖然穩定了,但是中心的Hub就變成單點隱患,如果中間的DockerHub掛了,整個系統也就廢了。
改進後的架構如下:
本質上仍然是一個星形網絡,只不過將hub弄成二個互備,然後每個hub都與其它外圍的broker相連,消費者連接到broker1/broker2/broker3,生產者(Producer)連接到hub1/hub2,消息的最長路徑不超過3個broker (注:生產者也可以連接到broker1/2/3,與消費者一樣,但是消息經過的最長路徑會變成4)
如果以後要擴張,比如增加了Broker4,Broker5...,直接修改hub1/2上的配置,增加與新的broker的連接即可,不影響消息的路由途徑長度。
最後,在本機演練一把,給出一些配置示例:
1、端口規劃
activemq1: 61616 (broker1) activemq2: 61626 (broker2) activemq3: 61636 (broker3) activemq4: 61646 (broker-hub1) activemq5: 61656 (broker-hub2)
共5個activemq實例,端口61616、61626、61636為broker1、broker2、broker3,61645、61656為broker-hub1、broker-hub2
2、activemq.xml配置
以boker1為例,配置文件內容如下:
1 <beans 2 xmlns="http://www.springframework.org/schema/beans" 3 xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" 4 xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd 5 http://activemq.apache.org/schema/core http://activemq.apache.org/schema/core/activemq-core.xsd"> 6 7 <bean class="org.springframework.beans.factory.config.PropertyPlaceholderConfigurer"> 8 <property name="locations"> 9 <value>file:${activemq.conf}/credentials.properties</value> 10 </property> 11 </bean> 12 13 <broker xmlns="http://activemq.apache.org/schema/core" brokerName="broker1"> 14 <persistenceAdapter> 15 <kahaDB directory="${activemq.data}/kahadb"/> 16 </persistenceAdapter> 17 <transportConnectors> 18 <transportConnector name="openwire" 19 uri="tcp://0.0.0.0:61616?maximumConnections=1000&wireFormat.maxFrameSize=104857600"/> 20 </transportConnectors> 21 </broker> 22 23 <import resource="jetty.xml"/> 24 </beans> View Codebroker2及broker3,大家參考該配置修改端口號及brokerName即可。
broker-hub1的配置:
1 <beans 2 xmlns="http://www.springframework.org/schema/beans" 3 xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" 4 xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd 5 http://activemq.apache.org/schema/core http://activemq.apache.org/schema/core/activemq-core.xsd"> 6 7 <bean class="org.springframework.beans.factory.config.PropertyPlaceholderConfigurer"> 8 <property name="locations"> 9 <value>file:${activemq.conf}/credentials.properties</value> 10 </property> 11 </bean> 12 13 <broker xmlns="http://activemq.apache.org/schema/core" brokerName="broker-hub1"> 14 <networkConnectors> 15 <networkConnector uri="static:(tcp://127.0.0.1:61656,tcp://127.0.0.1:61616,tcp://127.0.0.1:61626,tcp://127.0.0.1:61636)" duplex="true"/> 16 </networkConnectors> 17 <persistenceAdapter> 18 <kahaDB directory="${activemq.data}/kahadb"/> 19 </persistenceAdapter> 20 <transportConnectors> 21 <transportConnector name="openwire" 22 uri="tcp://0.0.0.0:61646?maximumConnections=1000&wireFormat.maxFrameSize=104857600"/> 23 </transportConnectors> 24 </broker> 25 26 <import resource="jetty.xml"/> 27 </beans> View Codebroker-hub2的配置:
1 <beans 2 xmlns="http://www.springframework.org/schema/beans" 3 xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" 4 xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd 5 http://activemq.apache.org/schema/core http://activemq.apache.org/schema/core/activemq-core.xsd"> 6 7 <bean class="org.springframework.beans.factory.config.PropertyPlaceholderConfigurer"> 8 <property name="locations"> 9 <value>file:${activemq.conf}/credentials.properties</value> 10 </property> 11 </bean> 12 13 <broker xmlns="http://activemq.apache.org/schema/core" brokerName="broker-hub2"> 14 <networkConnectors> 15 <networkConnector uri="static:(tcp://127.0.0.1:61616,tcp://127.0.0.1:61626,tcp://127.0.0.1:61636)" duplex="true"/> 16 </networkConnectors> 17 <persistenceAdapter> 18 <kahaDB directory="${activemq.data}/kahadb"/> 19 </persistenceAdapter> 20 <transportConnectors> 21 <transportConnector name="openwire" 22 uri="tcp://0.0.0.0:61656?maximumConnections=1000&wireFormat.maxFrameSize=104857600"/> 23 </transportConnectors> 24 </broker> 25 26 <import resource="jetty.xml"/> 27 </beans> View Code3、java代碼中spring配置文件
a) 生產者
1 <bean id="jmsFactory" class="org.apache.activemq.pool.PooledConnectionFactory" destroy-method="stop"> 2 <property name="connectionFactory"> 3 <bean class="org.apache.activemq.ActiveMQConnectionFactory"> 4 <!--broker服務的地址--> 5 <property name="brokerURL" value="failover:(tcp://localhost:61646,tcp://localhost:61656)"/> 6 <!--默認值為1000,如果不需要這麼大,可以調小--> 7 <property name="maxThreadPoolSize" value="100"/> 8 <!--<property name="userName" value="system"/>--> 9 <!--<property name="password" value="manager"/>--> 10 </bean> 11 </property> 12 </bean> View Codeb) 消費者
1 <bean id="jmsFactory" class="org.apache.activemq.pool.PooledConnectionFactory" destroy-method="stop"> 2 <property name="connectionFactory"> 3 <bean class="org.apache.activemq.ActiveMQConnectionFactory"> 4 <!--broker服務的地址--> 5 <property name="brokerURL" value="failover:(tcp://localhost:61616,tcp://localhost:61626,tcp://localhost:61636)"/> 6 <!--默認值為1000,如果不需要這麼大,可以調小--> 7 <property name="maxThreadPoolSize" value="100"/> 8 <!--<property name="userName" value="system"/>--> 9 <!--<property name="password" value="manager"/>--> 10 </bean> 11 </property> 12 </bean> View Code
參考文章:
http://www.jakubkorab.net/2011/11/understanding-activemq-broker-networks.html
http://activemq.apache.org/networks-of-brokers.html
