一、安裝准備
1.1平台環境：
CentOS 5.4 x86_64 GNU/Linux
nginx-0.8.21
PHP-5.2.9
spawn-fCGI-1.6.3
MySQL-5.1.34
1.2系統安裝及分區：1.2.1操作系統安裝： 1.2.3系統分區：
/boot 100M (大約100左右)
SWAP 4G 物理內存的2倍(如果你的物理內存大於4G，分配4G即可)
/ 50G
/data 剩余所有空間. 1.2.4系統軟件包安裝規范 軟件源代碼包存放位置 /usr/local/src
源碼包編譯安裝位置(prefix) /usr/local/software_name
腳本以及維護程序存放位置 /usr/local/sbin
MySQL 數據庫位置 /data/MySQL/data（可按情況設置）
網站根目錄 /data/www/wwwroot（可按情況設置）
虛擬主機日志根目錄 /data/logs（可按情況設置）
Nginx運行賬戶 www:www
install_software_name.sh //存放編譯參數腳本習慣將所有編譯腳本存放在install_software_name.sh便於升級和更新軟件.
1.3.系統初始化
#vi init_network.sh
#welcome
cat << EOF | === Welcome to Centos System init === | +----------------------Author:NetSeek--------------------------+
EOF
#disable ipv6
cat << EOF | === Welcome to Disable IPV6 === | EOF
echo "alias net-pf-10 off" >> /etc/modprobe.conf
echo "alias ipv6 off" >> /etc/modprobe.conf
/sbin/chkconfig --level 35 ip6tables off
echo "ipv6 is disabled!"
#disable seLinux
sed -i '/SELINUX/s/enforcing/disabled/' /etc/seLinux/config
echo "seLinux is disabled,you must reboot!"
#vim
sed -i "8 s/^/alias vi='vim'/" /root/.bashrc
echo 'syntax on' > /root/.vimrc
#zh_cn
sed -i -e 's/^LANG=.*/LANG="en"/' /etc/sysconfig/i18n
#init_ssh
ssh_cf="/etc/ssh/sshd_config"
sed -i -e '74 s/^/#/' -i -e '76 s/^/#/' $ssh_cf
sed -i "s/#UseDNS yes/UseDNS no/" $ssh_cf
#clIEnt
sed -i -e '44 s/^/#/' -i -e '48 s/^/#/' $ssh_cf
echo "ssh is init is ok.............."
#chkser
#tunoff services cat << EOF | === Welcome to Tunoff services === | EOF for i in `ls /etc/rc3.d/S*`
do
CURSRV=`echo $i|cut -c 15-`
echo $CURSRV
case $CURSRV in
crond | irqbalance | microcode_ctl | network | random | sendmail | sshd | syslog | local | MySQLd )
echo "Base services, Skip!" *)
echo "change $CURSRV to off"
chkconfig --level 235 $CURSRV off
service $CURSRV stop esac
done
1.4 系統環境部署及調整
檢查系統是否正常
# tail -n100 /var/log/messages （檢查有無系統級錯誤信息）
# dmesg （檢查硬件設備是否有錯誤信息）
# ifconfig （檢查網卡設置是否正確）
# ping （檢查網絡是否正常）
1.5使用 yum 程序安裝所需開發包
1.5.1 更換快源
#cd /etc/yum.repos.d/
#mv CentOS-Base.repo CentOS-Base.repo.Linuxtone
#wget http://docs.Linuxtone.org/soft/lemp/CentOS-Base.repo 1.5.2 yum安裝相關軟件包:
#yum -y install ntp vim-enhanced gcc gcc-c++ gcc-g77 flex bison autoconf automake glibc glibc-devel glib2 glib2-devel bzip2 bzip2-devel ncurses ncurses-devel libtool* zlib-devel libXML2-devel libjpeg-devel libpng-devel libtiff-devel fontconfig-devel freetype-devel libXpm-devel gettext-devel curl curl-devel pam-devel e2fsprogs-devel krb5-devel libidn libidn-devel openssl openssl-devel openldap openldap-devel nss_ldap openldap-clIEnts openldap-servers
1.6 定時校正服務器時鐘，定時與中國國家授時中心授時服務器同步
# crontab -e 15 3 * * * /usr/sbin/ntpdate 210.72.145.44 > /dev/null 2>&1
1.7下載相關軟件包
#cd /usr/local/src
#vi list_tar.list
http://docs.Linuxtone.org/soft/lemp/ImageMagick.tar.gz
http://docs.Linuxtone.org/soft/lemp/PDO_MySQL-1.0.2.tgz
http://docs.Linuxtone.org/soft/lemp/eaccelerator-0.9.5.3.tar.bz2
http://docs.Linuxtone.org/soft/lemp/imagick-2.2.2.tgz
http://docs.Linuxtone.org/soft/lemp/libiconv-1.13.tar.gz
http://docs.Linuxtone.org/soft/lemp/libmcrypt-2.5.8.tar.gz
http://docs.Linuxtone.org/soft/lemp/mcrypt-2.6.8.tar.gz
http://docs.Linuxtone.org/soft/lemp/memcache-2.2.5.tgz
http://docs.Linuxtone.org/soft/lemp/mhash-0.9.9.9.tar.gz
http://docs.Linuxtone.org/soft/lemp/MySQL-5.1.34.tar.gz
http://docs.Linuxtone.org/soft/lemp/pcre-7.8.tar.gz
http://www.lighttpd.Net/download/spawn-fCGI-1.6.3.tar.gz
http://docs.Linuxtone.org/soft/lemp/PHP-5.2.9.tar.bz2
http://sysoev.ru/nginx/nginx-0.8.21.tar.gz
http://docs.linuxtone.org/soft/lemp/ZendOptimizer-3.3.3-Linux-glibc23-x86_64.tar.gz #wget -i list_tar.list
1.8.添加nginx 運維賬戶:#vi add_webuser.sh
/usr/sbin/groupadd www
/usr/sbin/useradd -g www www
mkdir -p /data/www/wwwroot
chmod +w /data/www/wwwroot
chown www:www /data/www/wwwroot -R #sh add_webuser.sh
二.編譯安裝2.1 編譯安裝pcre#tar zxvf pcre-7.8.tar.gz
#cd pcre-7.8
#./configure && make && make install
2.2 編譯安裝nginx
#tar zxvf nginx-0.8.21.tar.gz
#cd nginx-0.8.21 2.2.1 附加：修改nginx源代碼，偽裝nginx服務器（僅供參考，安全還得認真做起^.^）：
(1).修改gcc
#vi auto/cc/gcc
NGX_GCC_OPT="-O" 修改為：
NGX_GCC_OPT="-O3" (2).修改nginx.h
#vi nginx-0.8.21/src/core/nginx.h
#define NGINX_VERSION "0.7.58"
#define NGINX_VER "nginx/" NGINX_VERSION 修改為：
#define NGINX_VERSION "1.0"
#define NGINX_VER "LTWS/" NGINX_VERSION (3).修改nginx_http_header_filter_module
#vi nginx-0.8.21/src/http/ngx_http_header_filter_module.c
static char ngx_http_server_string[] = "Server: nginx" CRLF; 修改為:
static char ngx_http_server_string[] = "Server: LTWS" CRLF; (4).修改ngx_http_special_response.c
#vi nginx-0.8.21/src/http/ngx_http_special_response.c static u_char ngx_http_error_full_tail[] =
"<hr><center>" NGINX_VER "</center>" CRLF
"</body>" CRLF
"</Html>" CRLF
; static u_char ngx_http_error_tail[] =
"<hr><center>nginx</center>" CRLF
"</body>" CRLF
"</Html>" CRLF static u_char ngx_http_error_full_tail[] =
"<hr><center> "NGINX_VER" </center>" CRLF
"<hr><center>http://www.Linuxtone.com</center>" CRLF
"</body>" CRLF
"</Html>" CRLF
; static u_char ngx_http_error_tail[] =
"<hr><center>HMGWS</center>" CRLF
"</body>" CRLF
"</Html>" CRLF
; 2.2.2 nginx 編譯安裝
./configure \
"--user=www" \
"--group=www" \
"--prefix=/usr/local/nginx/" \
"--with-http_stub_status_module" \
"--with-http_ssl_module" \
"--with-md5=/usr/lib" \
"--with-sha1=/usr/lib"
make
make install
2.3 編譯安裝配置MySQL
./configure \
"--prefix=/usr/local/MySQL" \
"--localstatedir=/data/MySQL/data" \
"--with-comment=Source" \
"--with-server-suffix=-Linuxtone.Org" \
"--enable-assembler" \
"--with-charset=gbk" \
"--with-collation=gbk_chinese_ci" \
"--with-collation=gbk_chinese_ci" \
"--with-extra-charsets=complex" \
"--enable-thread-safe-clIEnt" \
"--with-big-tables" \
"--with-readline" \
"--with-ssl" \
"--with-embedded-server" \
"--enable-local-infile" \
"--with-plugins=innobase"
make
make install
useradd mysql -d /data/MySQL -s /sbin/nologin
/usr/local/mysql/bin/mysql_install_db --user=MySQL
cd /usr/local/MySQL
chown -R root:MySQL .
mkdir -p /data/MySQL/data
chown -R mysql /data/MySQL/data
cp share/MySQL/my-huge.cnf /etc/my.cnf.bak
wget http://www.caifw.com/api/my.cnf
sed -i '50 s/^/#/' /etc/my.cnf
cp share/mysql/mysql.server /etc/rc.d/init.d/MySQLd
chmod 755 /etc/rc.d/init.d/MySQLd
chkconfig --add MySQLd
/etc/rc.d/init.d/mysqld start cd /usr/local/MySQL/bin
for i in *; do ln -s /usr/local/MySQL/bin/$i /usr/bin/$i; done
2.4 編譯安裝PHP
2.4.1安裝PHP相應的lib
2.4.1.1 libiconv-1.13
#tar zxvf libiconv-1.13.tar.gz
#cd libiconv-1.13
#./configure --prefix=/usr && make && make install 2.4.1.2 libmcrypt-2.5.8
#tar zxvf libmcrypt-2.5.8.tar.gz
#cd libmcrypt-2.5.8/
#./configure --prefix=/usr && make && make install
#echo "/usr/lib" >> /etc/ld.so.conf
#ldconfig
#cd libltdl/
#./configure --enable-ltdl-install
#make && make install 2.4.1.3 mhash-0.9.9.9
#tar zxvf mhash-0.9.9.9.tar.gz
#cd mhash-0.9.9.9
#./configure --prefix=/usr && make && make install
#ldconfig 2.4.1.4 mcrypt-2.6.8
#tar zxvf mcrypt-2.6.8.tar.gz
#cd mcrypt-2.6.8
#./configure --prefix=/usr && make&& make install
2.4.2 安裝spawn-fCGI
#tar zvxf spawn-fCGI-1.6.3.tar.gz
#cd spawn-fCGI-1.6.3
#./configure && make && make install
2.4.3 安裝PHP#tar jvxf PHP-5.2.9.tar.bz2
#vi install_PHP.sh
./configure \
"--prefix=/usr/local/PHP" \
"--enable-fastCGI" \
"--enable-fpm" \
"--enable-discard-path" \
"--enable-force-CGI-redirect" \
"--with-config-file-path=/usr/local/PHP/etc" \
"--with-mysql=/usr/local/MySQL" \
"--with-mysqli=/usr/local/mysql/bin/MySQL_config" \
"--with-iconv-dir" \
"--with-freetype-dir" \
"--with-jpeg-dir" \
"--with-png-dir" \
"--with-gd" \
"--with-zlib" \
"--with-libXML-dir" \
"--with-curl" \
"--with-curlwrappers" \
"--with-openssl" \
"--with-mhash" \
"--with-XMLrpc" \
"--with-mcrypt" \
"--with-ldap" \
"--with-ldap-sasl" \
"--enable-XML" \
"--disable-rpath" \
"--enable-discard-path" \
"--enable-safe-mode" \
"--enable-bcmath" \
"--enable-shmop" \
"--enable-sysvsem" \
"--enable-inline-optimization" \
"--enable-mbregex" \
"--enable-mbstring" \
"--enable-gd-native-ttf" \
"--enable-FTP" \
"--enable-pcntl" \
"--enable-sockets" \
"--enable-zip" \
"--disable-debug" \
"--disable-ipv6"
make ZEND_EXTRA_LIBS='-liconv'
make install
cp php.ini-dist /usr/local/php/etc/php.ini #sh install_PHP.sh
2.4.4安裝PHP擴展模塊
2.4.4.1 memcache-2.2.5
#tar zvxf memcache-2.2.5.tgz
#cd memcache-2.2.5
#/usr/local/php/bin/PHPize
#./configure --with-php-config=/usr/local/php/bin/PHP-config
#make && make install 2.4.4.2 eaccelerator-0.9.5.3
#tar jvxf eaccelerator-0.9.5.3.tar.bz2
#cd eaccelerator-0.9.5.3
#/usr/local/php/bin/PHPize
#./configure --enable-eaccelerator=shared --with-php-config=/usr/local/php/bin/PHP-config
#make && make install 2.4.4.3 PDO_MySQL-1.0.2
#tar zxvf PDO_MySQL-1.0.2.tgz
#cd PDO_MySQL-1.0.2
#/usr/local/php/bin/PHPize
#./configure --with-php-config=/usr/local/php/bin/PHP-config --with-pdo-mysql=/usr/local/MySQL
#make && make install 2.4.4.4 ImageMagick
#tar zxvf ImageMagick.tar.gz
#cd ImageMagick-6.5.1-2/
#./configure --enable-shared --with-modules --without-x --with-gs-font-dir=default --with-perl=yes --with-XML=yes --with-zlib=yes --with-jpeg=yes
# make && make install 2.4.4.5 imagick-2.2.2
#tar zxvf imagick-2.2.2.tgz
#cd imagick-2.2.2/
#/usr/local/php/bin/PHPize
#./configure --with-php-config=/usr/local/php/bin/PHP-config
#make
#make install
2.4.5腳本配置PHP.ini
# vi init_PHP.ini
#!/bin/bash
fCGI_cf="/usr/local/php/etc/PHP.ini"
ea(){
cat << EOF
[eAccelerator]
zend_extension="/usr/local/php/lib/PHP/extensions/no-debug-non-zts-20060613/eaccelerator.so"
eaccelerator.shm_size="32"
eaccelerator.cache_dir="/data/cache/ea"
eaccelerator.enable="1"
eaccelerator.optimizer="1"
eaccelerator.check_mtime="1"
eaccelerator.debug="0"
eaccelerator.filter=""
eaccelerator.shm_max="0"
eaccelerator.shm_ttl="0"
eaccelerator.shm_prune_period="0"
eaccelerator.shm_only="0"
eaccelerator.compress="1"
eaccelerator.compress_level="9"
EOF #mkdir
mkdir -p /data/cache/ea
ea >> $fCGI_cf
#config for PHP.ini
sed -i '205 s#;open_basedir =#open_basedir = /data/www/wwwroot:/tmp#g' $fCGI_cf
sed -i '210 s#disable_functions =#;disable_functions = PHPinfo,passthru,exec,system,chroot,scandir,chgrp,chown,shell_exec,proc_open,proc_get_status,ini_alter,ini_alter,ini_restore,dl,pfsockopen,openlog,syslog,readlink,symlink,popepassthru,stream_socket_server#g' $fCGI_cf
sed -i '/expose_PHP/s/On/Off/' $fCGI_cf
sed -i '/display_errors/s/On/Off/' $fCGI_cf
sed -i 's#extension_dir = "./"#extension_dir = "/usr/local/php/lib/PHP/extensions/no-debug-non-zts-20060613/"\nextension = "memcache.so"\nextension = "pdo_MySQL.so"\nextension = "imagick.so"\n#' $fCGI_cf
sed -i 's#output_buffering = Off#output_buffering = On#' $fCGI_cf
2.5安裝Zend#tar zvxf ZendOptimizer-3.3.3-Linux-glibc23-x86_64.tar.gz
# cd ZendOptimizer-3.3.3-Linux-glibc23-x86_64
# ./install 注：php.ini的位置為/usr/local/PHP/etc 服務器不選用apache
三、配置整合3.1 配置nginx注：本文spawn-fCGI開啟9000跟9001兩個端口，利用nginx的upstream負載均衡PHP程序到不同的fCGI端口上面，解決502 gateway錯誤
#cd /usr/local/nginx/conf
#cp nginx.conf nginx.conf.Linuxtone
#vi nginx.conf
user www www; worker_processes 10; pid /var/run/nginx.pid;
# [ debug | info | notice | warn | error | crit ]
error_log /dev/null;
#error_log /data/logs/nginxerror.log;
#SpecifIEs the value for maximum file descriptors that can be opened by this process.
worker_rlimit_nofile 51200; events use epoll; #maxclIEnt = worker_processes * worker_connections / cpu_number
worker_connections 51200;
} http include /usr/local/nginx/conf/mime.types;
default_type application/octet-stream;
#charset gb2312;
charset gbk;
log_format main '$remote_addr - $remote_user [$time_local] $request '
'"$status" $body_bytes_sent "$http_referer" '
'"$http_user_agent" "$http_x_forwarded_for"'; #access_log /data/www/logs/Access.log main;
Access_log /dev/null; #General Options
server_names_hash_bucket_size 128;
clIEnt_header_buffer_size 32k;
large_clIEnt_header_buffers 4 32k;
ignore_invalid_headers on;
recursive_error_pages on;
server_name_in_redirect off; sendfile on; #timeouts
keepalive_timeout 60; #TCP Options
tcp_nopush on;
tcp_nodelay on;
#fastCGI options
fastCGI_connect_timeout 300;
fastCGI_send_timeout 300;
fastcgi_read_timeout 300; fastCGI_buffer_size 128k;
fastCGI_buffers 4 128k;
fastCGI_busy_buffers_size 128k;
fastCGI_temp_file_write_size 128k;
fastCGI_intercept_errors on;
ssi on;
ssi_silent_errors on;
ssi_types text/sHtml;
#size limits
clIEnt_max_body_size 50m;
clIEnt_body_buffer_size 256k;
#gzip compression
gzip on;
gzip_min_length 0;
gzip_buffers 16 8k;
gzip_http_version 1.0;
gzip_comp_level 9;
gzip_types text/plain text/CSS image/x-icon image/png;
gzip_vary on; #temp files
proxy_temp_path /dev/shm/proxy_temp;
fastcgi_temp_path /dev/shm/fastCGI_temp;
client_body_temp_path /dev/shm/clIEnt_body_temp;
#client_body_temp_path /usr/local/nginx/clIEnt_body_temp 1 2;
#proxy_temp_path /usr/local/nginx/proxy_temp 1 2;
#fastcgi_temp_path /usr/local/nginx/fastCGI_temp 1 2; #upstream
upstream spawn {
# ip_hash;
server 127.0.0.1:9000 max_fails=0 fail_timeout=30s;
server 127.0.0.1:9001 max_fails=0 fail_timeout=30s;
} # The following includes are specifIEd for virtual hosts
#www.Linuxtone.org
include /usr/local/nginx/conf/vhosts/www.Linuxtone.org.conf;
} #mkdir vhosts
#vi vhosts/www.Linuxtone.org.conf
server listen 80;
server_name www.linuxtone.org .Linuxtone.org;
index index.Html index.htm index.PHP;
root /data/www/wwwroot/Linuxtone;
error_page 404 http://www.Linuxtone.org;
#rewrite ^/bbs/(.*) http://bbs.Linuxtone.org/$1;
location ~ .*\.PHP?$ fastCGI_pass spawn;
include /usr/local/nginx/conf/spawn_PHP5.conf;
fastCGI_index index.PHP; location ~* \.(JS|CSS|jpg|jpeg|gif|png)$ {
if (-f $request_filename) {
Access_log off;
expires 1d;
break; }
} #vi /usr/local/nginx/conf/spawn_PHP5.conf
fastcgi_param GATEWAY_INTERFACE CGI/1.1;
fastCGI_param SERVER_SOFTWARE nginx;
fastCGI_param QUERY_STRING $query_string;
fastCGI_param REQUEST_METHOD $request_method;
fastCGI_param CONTENT_TYPE $content_type;
fastCGI_param CONTENT_LENGTH $content_length;
fastcgi_param SCRIPT_FILENAME $document_root$fastCGI_script_name;
fastcgi_param SCRIPT_NAME $fastCGI_script_name;
fastCGI_param REQUEST_URI $request_uri;
fastCGI_param DOCUMENT_URI $document_uri;
fastCGI_param DOCUMENT_ROOT $document_root;
fastCGI_param SERVER_PROTOCOL $server_protocol;
fastCGI_param REMOTE_ADDR $remote_addr;
fastCGI_param REMOTE_PORT $remote_port;
fastCGI_param SERVER_ADDR $server_addr;
fastCGI_param SERVER_PORT $server_port;
fastCGI_param SERVER_NAME $server_name;
# PHP only, required if PHP was built with --enable-force-CGI-redirect
#fastCGI_param REDIRECT_STATUS 200;
3.2 配置spawn-fCGI啟動腳本#mkdir /usr/local/PHP/sbin
# vi /usr/local/PHP/sbin/spawn-fCGI
#! /bin/sh set -e PATH=/usr/local/sbin:/usr/local/bin:/sbin:/bin:/usr/sbin:/usr/bin
DESC="spawn-fCGI daemon"
NAME=spawn-fCGI
DAEMON=/usr/local/bin/$NAME # Gracefully exit if the package has been removed.
test -x $DAEMON || exit 0 d_start() {
$DAEMON -a 127.0.0.1 -p 9000 -C 128 -u www -g www -f /usr/local/php/bin/PHP-CGI > /dev/null 2>&1
$DAEMON -a 127.0.0.1 -p 9001 -C 128 -u www -g www -f /usr/local/php/bin/PHP-CGI > /dev/null 2>&1 || echo -n " already running"
} d_stop() {
/usr/bin/killall -9 PHP-CGI > /dev/null 2>&1 || echo -n " not running"
} case "$1" in
start)
echo -n "Starting $DESC: $NAME"
d_start
echo "." stop)
echo -n "Stopping $DESC: $NAME"
d_stop
echo "." restart)
echo -n "Restarting $DESC: $NAME"
d_stop
sleep 1
d_start
echo "." *)
echo "Usage: $SCRIPTNAME {start|stop|restart}" >&2
exit 3 esac exit 0 #chmod 755 /usr/local/PHP/sbin/spawn-fCGI
四、啟動WEB服務4.1.啟動spawn-fCGI
#/usr/local/PHP/sbin/spawn-fCGI start
4.2.啟動nginx4.2.1檢查nginx配置：
# /usr/local/nginx/sbin/nginx –t //返回如下信息說明配置正確
the configuration file /usr/local/nginx//conf/nginx.conf syntax is ok
configuration file /usr/local/nginx//conf/nginx.conf test is successful #/usr/local/nginx/sbin/nginx //啟動nginx
4.3.加入開機啟動
#vi /etc/rc.local ulimit -SHn 51200
/usr/local/nginx/sbin/nginx
/usr/local/PHP/sbin/spawn-fCGI start
五、測試
#mkdir /data/www/wwwroot/Linuxtone
#vi phpinfo.PHP
<?PHP
PHPinfo();
?> 打開浏覽器輸入：http://www.Linuxtone.org/phpinfo.PHP
