關於同步數據篇:主要講解理清業務思路,下一篇:同步數據(依據業務需求):【將數據庫中sys_Menu數據添加到sys_Menu_Copy】
TODO:
1,表【sys_Menu_Copy】已存在數據,過濾
2,表【sys_Menu_Copy】未存在數據,添加
講解篇:1,窗體設計器生成的代碼2,後台cs代碼:
1,窗體設計器生成的代碼
namespace DataSynchronousBWokerUI { partial class MainForm { /// <summary> /// 必需的設計器變量。 /// </summary> private System.ComponentModel.IContainer components = null; /// <summary> /// 清理所有正在使用的資源。 /// </summary> /// <param name="disposing">如果應釋放托管資源,為 true;否則為 false。</param> protected override void Dispose(bool disposing) { if (disposing && (components != null)) { components.Dispose(); } base.Dispose(disposing); } #region Windows 窗體設計器生成的代碼 /// <summary> /// 設計器支持所需的方法 - 不要 /// 使用代碼編輯器修改此方法的內容。 /// </summary> private void InitializeComponent() { System.ComponentModel.ComponentResourceManager resources = new System.ComponentModel.ComponentResourceManager(typeof(MainForm)); this.label = new System.Windows.Forms.Label(); this.btStop = new System.Windows.Forms.Button(); this.btStart = new System.Windows.Forms.Button(); this.label4 = new System.Windows.Forms.Label(); this.label5 = new System.Windows.Forms.Label(); this.label6 = new System.Windows.Forms.Label(); this.listBox1 = new System.Windows.Forms.ListBox(); this.progressBar1 = new System.Windows.Forms.ProgressBar(); this.tableLayoutPanel1 = new System.Windows.Forms.TableLayoutPanel(); this.tableLayoutPanel1.SuspendLayout(); this.SuspendLayout(); // // label // this.label.AutoSize = true; this.label.Location = new System.Drawing.Point(170, 67); this.label.Name = "label"; this.label.Size = new System.Drawing.Size(0, 12); this.label.TabIndex = 13; // // btStop // this.btStop.Anchor = System.Windows.Forms.AnchorStyles.None; this.btStop.BackgroundImage = ((System.Drawing.Image)(resources.GetObject("btStop.BackgroundImage"))); this.btStop.Font = new System.Drawing.Font("宋體", 14.25F, System.Drawing.FontStyle.Regular, System.Drawing.GraphicsUnit.Point, ((byte)(0))); this.btStop.Location = new System.Drawing.Point(212, 53); this.btStop.Name = "btStop"; this.btStop.Size = new System.Drawing.Size(203, 44); this.btStop.TabIndex = 12; this.btStop.Text = "取消同步"; this.btStop.Click += new System.EventHandler(this.btStop_Click); // // btStart // this.btStart.Anchor = System.Windows.Forms.AnchorStyles.None; this.btStart.BackgroundImage = ((System.Drawing.Image)(resources.GetObject("btStart.BackgroundImage"))); this.btStart.Font = new System.Drawing.Font("宋體", 14.25F, System.Drawing.FontStyle.Regular, System.Drawing.GraphicsUnit.Point, ((byte)(0))); this.btStart.Location = new System.Drawing.Point(3, 53); this.btStart.Name = "btStart"; this.btStart.Size = new System.Drawing.Size(203, 44); this.btStart.TabIndex = 11; this.btStart.Text = "同步數據"; this.btStart.Click += new System.EventHandler(this.btStart_Click); // // label4 // this.label4.AutoSize = true; this.label4.Location = new System.Drawing.Point(33, 143); this.label4.Name = "label4"; this.label4.Size = new System.Drawing.Size(0, 12); this.label4.TabIndex = 14; // // label5 // this.label5.AutoSize = true; this.label5.Image = ((System.Drawing.Image)(resources.GetObject("label5.Image"))); this.label5.Location = new System.Drawing.Point(122, 142); this.label5.Name = "label5"; this.label5.Size = new System.Drawing.Size(0, 12); this.label5.TabIndex = 15; // // label6 // this.label6.AutoSize = true; this.label6.Image = ((System.Drawing.Image)(resources.GetObject("label6.Image"))); this.label6.Location = new System.Drawing.Point(209, 142); this.label6.Name = "label6"; this.label6.Size = new System.Drawing.Size(0, 12); this.label6.TabIndex = 16; // // listBox1 // this.listBox1.Anchor = ((System.Windows.Forms.AnchorStyles)((((System.Windows.Forms.AnchorStyles.Top | System.Windows.Forms.AnchorStyles.Bottom) | System.Windows.Forms.AnchorStyles.Left) | System.Windows.Forms.AnchorStyles.Right))); this.listBox1.BackColor = System.Drawing.Color.White; this.listBox1.ForeColor = System.Drawing.SystemColors.InactiveCaptionText; this.listBox1.FormattingEnabled = true; this.listBox1.ItemHeight = 12; this.listBox1.Location = new System.Drawing.Point(1, 57); this.listBox1.Name = "listBox1"; this.listBox1.Size = new System.Drawing.Size(417, 184); this.listBox1.TabIndex = 17; // // progressBar1 // this.progressBar1.Anchor = ((System.Windows.Forms.AnchorStyles)(((System.Windows.Forms.AnchorStyles.Top | System.Windows.Forms.AnchorStyles.Left) | System.Windows.Forms.AnchorStyles.Right))); this.progressBar1.Location = new System.Drawing.Point(1, 12); this.progressBar1.Name = "progressBar1"; this.progressBar1.Size = new System.Drawing.Size(417, 30); this.progressBar1.TabIndex = 18; // // tableLayoutPanel1 // this.tableLayoutPanel1.ColumnCount = 2; this.tableLayoutPanel1.ColumnStyles.Add(new System.Windows.Forms.ColumnStyle(System.Windows.Forms.SizeType.Percent, 50F)); this.tableLayoutPanel1.ColumnStyles.Add(new System.Windows.Forms.ColumnStyle(System.Windows.Forms.SizeType.Percent, 50F)); this.tableLayoutPanel1.Controls.Add(this.btStart, 0, 1); this.tableLayoutPanel1.Controls.Add(this.btStop, 1, 1); this.tableLayoutPanel1.Dock = System.Windows.Forms.DockStyle.Bottom; this.tableLayoutPanel1.Location = new System.Drawing.Point(0, 243); this.tableLayoutPanel1.Name = "tableLayoutPanel1"; this.tableLayoutPanel1.RowCount = 2; this.tableLayoutPanel1.RowStyles.Add(new System.Windows.Forms.RowStyle(System.Windows.Forms.SizeType.Percent, 50F)); this.tableLayoutPanel1.RowStyles.Add(new System.Windows.Forms.RowStyle(System.Windows.Forms.SizeType.Percent, 50F)); this.tableLayoutPanel1.Size = new System.Drawing.Size(419, 100); this.tableLayoutPanel1.TabIndex = 19; // // MainForm // this.BackgroundImage = global::DataSynchronousBWokerUI.Properties.Resources._1234564578798798798797987987987987; this.ClientSize = new System.Drawing.Size(419, 343); this.Controls.Add(this.tableLayoutPanel1); this.Controls.Add(this.progressBar1); this.Controls.Add(this.listBox1); this.Controls.Add(this.label6); this.Controls.Add(this.label5); this.Controls.Add(this.label4); this.Controls.Add(this.label); this.FormBorderStyle = System.Windows.Forms.FormBorderStyle.FixedSingle; this.Icon = ((System.Drawing.Icon)(resources.GetObject("$this.Icon"))); this.Name = "MainForm"; this.StartPosition = System.Windows.Forms.FormStartPosition.CenterScreen; this.Text = "測試:同步數據"; this.tableLayoutPanel1.ResumeLayout(false); this.ResumeLayout(false); this.PerformLayout(); } #endregion private System.Windows.Forms.Label label; private System.Windows.Forms.Button btStop; private System.Windows.Forms.Button btStart; private System.Windows.Forms.Label label4; private System.Windows.Forms.Label label5; private System.Windows.Forms.Label label6; private System.Windows.Forms.ListBox listBox1; private System.Windows.Forms.ProgressBar progressBar1; private System.Windows.Forms.TableLayoutPanel tableLayoutPanel1; } }2,後台cs代碼
1,定義線程名,線程開始標識,連接服務器成功標識,退出程序標識,源數據庫,目標數據庫
private Thread preg;//線程名 private bool tureOfalse;//線程執行標識 public bool conYes;//連接服務成功失敗標識 private bool one = false;//退出程序標識 string strdbHipis = System.Configuration.ConfigurationManager.AppSettings["NewHmFrameWork_QHS_SQ"].ToString();//源數據庫 //string strdbPreg = System.Configuration.ConfigurationManager.AppSettings["NewHmFrameWork_QHS_SQ_QingHai"].ToString();//目標數據庫 string strdbPreg = System.Configuration.ConfigurationManager.ConnectionStrings["NewHmFrameWork_QHS_SQ"].ToString();//目標數據庫
2,主方法實行調用:
public MainForm() { InitializeComponent(); btStop.Enabled = false;//未開啟進程,不允許取消進程 //委托 InitTrayIcon();//圖標托盤委托 Control.CheckForIllegalCrossThreadCalls = false;//線程委托 this.FormClosing += new FormClosingEventHandler(form_Closing);//退出程序委托 }
3,圖標聲明
//圖標聲明 NotifyIcon trayIcon = new NotifyIcon(); //圖標路徑C:\Users\Administrator\Desktop\DataSynchronousBWokerUI\DataSynchronousBWokerUI\Images\_net_32.ico private Icon mNetTrayIcon = new Icon("..//Images//_net_32.ico");
4,線程開始
//線程開始 private void btStart_Click(object sender, EventArgs e) { tureOfalse = true; preg = new Thread(new ThreadStart(PREG)); preg.Start(); btStart.Enabled = false; btStop.Enabled = true; }
5,線程方法
//線程方法 private void PREG() { do { listBox1.Items.Add("正在連接源數據庫... ...!"); listBox1.Items.Add("正在連接目標數據庫... ...!"); ISopenCon(); } while (!conYes); DoWork_select(); }
6,線程停止
//線程停止 private void btStop_Click(object sender, EventArgs e) { tureOfalse = false; preg.Abort(); /*2015/2/2 調整:點擊[取消同步],清空listbox當前數據*/ this.listBox1.Items.Clear(); listBox1.Items.Add("待同步... ..."); //控件顯示隱藏 btStart.Enabled = true; btStop.Enabled = false; }
7,連接目標數據庫失敗將信息寫入LOG
/// <summary> /// 連接目標數據庫失敗將信息寫入LOG /// </summary> /// <param name="sender"></param> /// <param name="e"></param> private void fslog(Exception ex) { string filepath = DateTime.Now.ToString("yyyyMMdd") + ".log"; FileStream fs = new FileStream(filepath, FileMode.Append, FileAccess.Write); StreamWriter sw = new StreamWriter(fs); DateTime time = DateTime.Now; sw.WriteLine(time); //sw.WriteLine("連接目標數據庫失敗"); sw.WriteLine(ex.Message); sw.WriteLine("---------------------------------------------------------"); sw.Close(); fs.Close(); }
8,嘗試連接源、目標數據庫
/// <summary> /// 嘗試連接源、目標數據庫 /// </summary> /// <param name="sender"></param> /// <param name="e"></param> private void ISopenCon() { try { SqlConnection conhipis = new SqlConnection(strdbHipis); conhipis.Open(); conYes = true; conhipis.Close(); SqlConnection conPreg = new SqlConnection(strdbPreg); conPreg.Open(); conYes = true; conPreg.Close(); } catch (Exception ex) { conYes = false; fslog(ex); listBox1.Items.Add("連接數據庫失敗......"); Thread.Sleep(60000); } }
9,嘗試刪除目標數據庫
/// <summary> /// 嘗試刪除目標數據庫 /// </summary> /// <param name="sender"></param> /// <param name="e"></param> private void DelPreg() { //try //{ //bool delResult = true; ////插入數據之前,先刪除當前社區的已有數據 //string strDelSQL = "delete from dbo.sys_Menu "; //strDelSQL += "delete from dbo.sys_MenuInRoles "; //strDelSQL += "delete from dbo.sys_UsersInRoles "; //delResult = ExecuteSql(strDelSQL); //if (delResult == false) //{ // //this.label4.Text = "刪除目標數據庫失敗......"; // listBox1.Items.Add("刪除目標數據庫失敗......"); //} //else //{ // //this.label4.Text = "刪除目標數據庫成功......"; // listBox1.Items.Add("刪除目標數據庫成功......"); //} /*測試數據:刪除dbo.sys_Menu_Copy在測試期間錄入的數據便於二次錄入<多次錄入>*/ SqlConnection hipiscon; SqlCommand SQLcom; hipiscon = new SqlConnection(strdbHipis); string strDelSQL = "delete from dbo.sys_Menu_Copy "; SQLcom = new SqlCommand(strDelSQL, hipiscon); try { hipiscon.Open(); SQLcom.ExecuteNonQuery(); hipiscon.Close(); listBox1.Items.Add("刪除目標數據庫成功......"); } catch (Exception ex) { listBox1.Items.Add("刪除目標數據庫失敗......"); fslog(ex); //Thread.Sleep(300000); } //} //catch (Exception ex) //{ // conYes = false; // fslog(ex); // listBox1.Items.Add("刪除目標數據庫失敗......"); // Thread.Sleep(60000); //} }
/// <summary> /// 對源庫操作 /// </summary> /// <param name="sender"></param> /// <param name="e"></param> private DataTable IsOpenDT(string strSQL, string strConn) { SqlConnection hipiscon; SqlCommand SQLcom; DataTable DT; SqlDataAdapter SQLADA; hipiscon = new SqlConnection(strConn); SQLcom = new SqlCommand(strSQL, hipiscon); try { hipiscon.Open(); SQLcom.ExecuteNonQuery(); conYes = true; hipiscon.Close(); } catch (Exception ex) { conYes = false; fslog(ex); //Thread.Sleep(300000); } DT = new DataTable(); SQLADA = new SqlDataAdapter(SQLcom); SQLADA.Fill(DT); return DT; } /// <summary> /// 對目標庫操作 /// </summary> /// <param name="sender"></param> /// <param name="e"></param> private void IsOpen(string strsql, string strconn) { try { SqlConnection pregcon = new SqlConnection(strconn); SqlCommand sqlcom = new SqlCommand(strsql, pregcon); pregcon.Open(); sqlcom.ExecuteNonQuery(); conYes = true; pregcon.Close(); } catch (Exception ex) { conYes = false; fslog(ex); //Thread.Sleep(300000); } }
11,具體操作方法
/// <summary> /// /// </summary> /// <param name="sender"></param> /// <param name="sender"></param> /// <param name="sender"></param> /// <param name="e"></param> private void DoWork_select() { //string strtb = System.Configuration.ConfigurationManager.AppSettings["strtable"].ToString(); //string strupdt = System.Configuration.ConfigurationManager.AppSettings["updt"].ToString(); //string strwhere = System.Configuration.ConfigurationManager.AppSettings["where"].ToString(); while (tureOfalse) { ISopenCon(); /*2015/2/2 調整:不能把菜單全部刪除,沒有的添加到服務器上去,已存在的過濾掉*/ //DelPreg(); //DataTable dt = IsOpenDT(strSQL, strdbHipis); //String[] tablenamekey = new String[3] { "dbo.sys_Menu", "dbo.sys_MenuInRoles", "dbo.sys_UsersInRoles" };//源數據庫 //String[] tablenamekeypreg = new String[3] { "dbo.sys_Menu_Copy", "dbo.sys_MenuInRoles_Copy", "dbo.sys_UsersInRoles_Copy" };//目標數據庫 //測試數據 String[] tablenamekey = new String[1] { "dbo.sys_Menu" };//源數據庫 String[] tablenamekeypreg = new String[1] { "dbo.sys_Menu_Copy" };//目標數據庫 if (tablenamekey.Length > 0) { for (int i = 0; i < tablenamekey.Length; i++) { string strtablenamekey = tablenamekey[i]; string strSQL1 = "select * from "; strSQL1 += strtablenamekey; strSQL1 += " where (1=1)"; insert_OR_update(strdbHipis, ref strSQL1, tablenamekeypreg[i]); } } } } /// <summary> /// 插入,更新 最新數據到PIS數據庫 /// </summary> /// <param name="con">需要更新的表的連接字符串</param> /// <param name="lastSQL">最後SQL語句</param> /// <param name="tbName">需要操作的表</param> private void insert_OR_update(string strdbHipis, ref string strSQL, string tbName) { int a = 0; int b = 0; string lastSQL; DataTable dttb; DataTable dttb1; dttb = IsOpenDT(strSQL, strdbHipis); /*2015/2/2 調整:新增[進度條]追加顯示加載信息*/ progressBar1.Maximum = dttb.Rows.Count;//設置最大長度值 progressBar1.Value = 0;//設置當前值 progressBar1.Step = 1;//設置每次增長1條數據 listBox1.Items.Add("連接源數據庫成功......"); listBox1.Items.Add("連接目標數據庫成功......"); listBox1.Items.Add("正在同步... ..."); try { for (int i = 0; i < dttb.Rows.Count; i++)//根據判斷條件循環更新數據庫中的信息 { /*2015/2/2 調整:不能把菜單全部刪除,沒有的添加到服務器上去,已存在的過濾掉*/ lastSQL = "select * from " + tbName + " where sCode= '" + dttb.Rows[i][0].ToString().Trim() + "'"; //更新dttb1:一條記錄 判斷是否存在<過濾:新增> /*測試數據庫:源庫和目標庫一致 後期調整目標庫連接字符串*/ dttb1 = IsOpenDT(lastSQL, strdbPreg); //目標庫中存在一條數據 取消 if (dttb1 != null && dttb1.Rows.Count > 0) { a = a + 1; listBox1.Items.Add("已過濾" + a.ToString() + "條!"); } else { string valuse = ""; string allcolumName = ""; for (int j = 0; j < dttb1.Columns.Count; j++) { if (j == dttb1.Columns.Count - 1) { allcolumName += dttb1.Columns[j].ColumnName.ToString(); } else { allcolumName += dttb1.Columns[j].ColumnName.ToString() + ","; } } //如果在線庫中的時間為空則進行插入操作 for (int j = 0; j < dttb.Columns.Count; j++) { if (j == dttb.Columns.Count - 1) { valuse += "'" + dttb.Rows[i][j].ToString() + "'"; } else { valuse += "'" + dttb.Rows[i][j] + "',"; } } lastSQL = "insert into " + tbName + " (" + allcolumName + ") values (" + valuse + ")"; IsOpen(lastSQL, strdbPreg); b = b + 1; listBox1.Items.Add("已插入" + b.ToString() + "條!"); } /*2015/2/2 調整:新增[進度條]追加顯示加載信息*/ progressBar1.Value += progressBar1.Step;//讓進度條增加一次 } } catch (Exception ex) { fslog(ex); } if ((a + b) > 0) { listBox1.Items.Add(tbName + "成功過濾" + a + "條數據條數據,成功插入" + b + "條數據!"); listBox1.Items.Add(tbName + "同步數據成功!"); //tureOfalse = false; preg.Abort();//線程執行標識:同步成功 關閉線程 //UPINlog(a, b, tbName); } else { listBox1.Items.Add(""); } }
12,此段代碼相當於sqlhelper.cs功能【連接數據庫】:
/// <summary> /// 執行SQL語句 /// </summary> /// <param name="SQLString">SQL語句</param> /// <returns>bool值,成功返回true,失敗返回false</returns> public static bool ExecuteSql(string SQLString) { bool isSucc = false; using (SqlConnection connection = new SqlConnection("Data Source=192.168.44.161;Initial Catalog=NewHmFrameWork_QHS_SQ_QingHai;Persist Security Info=True;User ID=sa;Password=jqkj123$%^;")) { connection.Open(); using (SqlTransaction trans = connection.BeginTransaction()) { using (SqlCommand cmd = new SqlCommand(SQLString, connection)) { cmd.Transaction = trans; int rows = cmd.ExecuteNonQuery(); trans.Commit(); isSucc = true; } } } return isSucc; }
13,初始化托盤圖標
/// <summary> /// 初始化托盤圖標 /// </summary> public void InitTrayIcon() { // 設置托盤圖標的菜單 trayIcon.Icon = mNetTrayIcon; trayIcon.Text = "單擊最大化程序"; trayIcon.Visible = true; trayIcon.Click += new EventHandler(trayIcon_Click); MenuItem[] mnuItems = new MenuItem[4]; mnuItems[0] = new MenuItem(); mnuItems[0].Text = "顯示"; mnuItems[0].Click += new EventHandler(Item0_Click); mnuItems[1] = new MenuItem(); mnuItems[1].Text = "隱藏"; mnuItems[1].Click += new EventHandler(Item1_Click); mnuItems[2] = new MenuItem("-"); mnuItems[3] = new MenuItem(); mnuItems[3].Text = "退出程序"; mnuItems[3].Click += new EventHandler(Item3_Click); trayIcon.ContextMenu = new ContextMenu(mnuItems); }
14,顯示窗體,隱藏窗體,退出事件,點擊托盤圖標,單擊X退出程序,
/// <summary> /// 顯示窗體 /// </summary> /// <param name="sender"></param> /// <param name="e"></param> void Item0_Click(object sender, EventArgs e) { this.Show(); } /// <summary> /// 隱藏窗體 /// </summary> /// <param name="sender"></param> /// <param name="e"></param> void Item1_Click(object sender, EventArgs e) { this.Hide(); this.trayIcon.ShowBalloonTip(5, "提示", "單擊最大化程序", ToolTipIcon.Info); } /// <summary> /// 退出事件 /// </summary> /// <param name="sender"></param> /// <param name="e"></param> void Item3_Click(object sender, EventArgs e) { preg.Abort(); Application.Exit(); } /// <summary> /// 點擊托盤圖標 /// </summary> /// <param name="sender"></param> /// <param name="e"></param> void trayIcon_Click(object sender, EventArgs e) { this.Visible = true; this.WindowState = FormWindowState.Maximized; } /// <summary> /// 單擊X退出程序 /// </summary> /// <param name="sender"></param> /// <param name="e"></param> private void form_Closing(object sender, FormClosingEventArgs e) { if (one == false) { DialogResult dia = MessageBox.Show("是否真的退出程序!", " ", MessageBoxButtons.OKCancel); if (dia == DialogResult.Cancel) { e.Cancel = true; this.Show(); this.trayIcon.Visible = true; } if (dia == DialogResult.OK) { one = true; /*2015/2/2 調整:退出[未同步時,直接退出]*/ preg = new Thread(new ThreadStart(PREG)); preg.Start(); preg.Abort(); Application.Exit(); } } }
